Mechatronic systems
Components for precise positioning devices
Type series of intelligent servo amplifiers. The AC servo is a device used to power a synchronous motor with permanent magnets. This is used for position the devices connected to the motor shaft to which the gearbox can be connected. Positioning accuracy is ensured by two sensors, first sensor (resolver) measure the position of the motor shaft and second sensor (encoder) measure the position of the gearbox output shaft, thus the drive shaft of driven system.


SMAC500
Power Supply Voltage: 19V – 32VDC
Input Current: 26A
Phase Current: 25A
Overload Factor: 1,2x
Power: 498VA
Protections: yes
Inputs: absolute sensor, shaft sensor, temperature sensor
Logical Input: 5x
IP: IP65
Connectors: MIL38999
Working temperature range: -32°C to +55ºC
Storage temperature range: -40ºC to +70ºC
Standards: MIL-STD 810G, ČOS999902, EN 60146-1-1
Input Current: 26A
Phase Current: 25A
Overload Factor: 1,2x
Power: 498VA
Protections: yes
Inputs: absolute sensor, shaft sensor, temperature sensor
Logical Input: 5x
IP: IP65
Connectors: MIL38999
Working temperature range: -32°C to +55ºC
Storage temperature range: -40ºC to +70ºC
Standards: MIL-STD 810G, ČOS999902, EN 60146-1-1

SMAC2000
Power Supply Voltage: 19V – 32VDC
Input Current:50A
Phase Current:130A
Overload Factor:1,2x
Power: 2000VA
Protections: yes
Inputs – absolute sensor, shaft sensor, temperature sensor
Logical Inputs: 5x
Connectors: MIL38999
IP: IP65
Working temperature range: -32°C to +55ºC
Storage temperature range: -40ºC to +70ºC
Standards: MIL-STD 810G, ČOS999902, EN 60146-1-1
Input Current:50A
Phase Current:130A
Overload Factor:1,2x
Power: 2000VA
Protections: yes
Inputs – absolute sensor, shaft sensor, temperature sensor
Logical Inputs: 5x
Connectors: MIL38999
IP: IP65
Working temperature range: -32°C to +55ºC
Storage temperature range: -40ºC to +70ºC
Standards: MIL-STD 810G, ČOS999902, EN 60146-1-1
